TokenForge

TokenForge

TokenForge is a lightweight JWT/signature toolkit for ProcessWire modules and integrations. It creates, signs and caches HS256, RS256 and ES256 JWTs for external services such as Apple WeatherKit, Android/Firebase-style service accounts, Samsung services and generic bearer-token APIs.

If this project helps your work, consider supporting future development: GitHub Sponsors or smnv.org/sponsor.

Author

Maxim Semenov
smnv.org
maxim@smnv.org

What is TokenForge

TokenForge is a reusable ProcessWire module for modules that need signed tokens when authenticating with external APIs.

• Generates JWT tokens with HS256, RS256 and ES256.
• Supports standalone ES256 signing for Apple .p8 keys.
• Includes admin playbooks and presets for Apple, Android/Firebase, Samsung-style service assertions and generic APIs.
• Quick presets include demo signing material so the generator can be tested immediately.
• Converts OpenSSL DER ECDSA signatures to JOSE R || S format.
• Supports cached token creation through ProcessWire cache.
• Provides strict TTL enforcement against expired payloads.
• Loads private keys from files without storing key contents in module settings.
• Provides a superuser-only admin UI for generation, validation, diagnostics, profiles and provider-oriented setup guidance.

What TokenForge is not

TokenForge is not a REST API authentication module. It is a reusable JWT/signature toolkit for ProcessWire modules that need to authenticate with external services.

It does not:

• expose a REST API;
• manage frontend or backend user login;
• replace AppApi, RestApi or ProcessWire permissions;
• store global service credentials in module settings.

Installation

Requires PHP 8.1+ and ProcessWire 3+.

1. Copy the TokenForge folder into /site/modules/.
2. In ProcessWire Admin, refresh module list.
3. Install TokenForge (the ProcessTokenForge admin process is installed with it).
4. Open /admin/setup/token-forge/ to use the management UI.

Module settings

TokenForge settings are intentionally limited to safe admin defaults:

• default cached token TTL shown in generator and presets;
• private key path hint used in placeholders;
• cache key prefix hint used in examples;
• visibility of official documentation links.

Settings do not store private keys, shared secrets or generated JWTs.

Basic usage

$tokenForge = $modules->get('TokenForge');
$jwt = $tokenForge->createJwt([
 'algorithm' => 'HS256',
 'secret' => 'super-long-secret',
 'payload' => [
 'iss' => 'my-service',
 'iat' => time(),
 'exp' => time() + 3600,
 'aud' => 'api.example.com',
 ],
]);

ES256 usage

ES256 requires an EC P-256 private key. Apple WeatherKit .p8 keys use this format.

$jwt = $modules->get('TokenForge')->createJwt([
 'algorithm' => 'ES256',
 'key_id' => 'ABC123DEFG',
 'private_key_path' => '/site/assets/private/AuthKey_ABC123DEFG.p8',
 'headers' => [
 'id' => 'TEAMID.org.smnv.weather',
 ],
 'payload' => [
 'iss' => 'TEAMID',
 'iat' => time(),
 'exp' => time() + 3600,
 'sub' => 'org.smnv.weather',
 ],
]);

Apple service tokens

Several Apple APIs use ES256 JWTs signed with an Apple .p8 private key. TokenForge's Apple preset is a starting point, not a WeatherKit-only form.

Common examples:

• WeatherKit REST API: Team ID, Services ID, Key ID, .p8.
• MapKit JS / Apple Maps Server API: Team ID, Maps ID, Key ID, .p8.
• APNs provider tokens: Team ID, APNs Key ID, .p8.
• App Store Connect / App Store Server APIs: Issuer ID, Key ID, .p8.
• MusicKit / DeviceCheck: Team ID, Key ID, .p8.

Apple WeatherKit example

$token = $modules->get('TokenForge')->createCachedJwt('apple_weatherkit', [
 'ttl' => 3300,
 'algorithm' => 'ES256',
 'key_id' => 'APPLE_KEY_ID',
 'private_key_path' => '/site/assets/private/AuthKey_APPLE_KEY_ID.p8',
 'headers' => [
 'id' => 'APPLE_TEAM_ID.com.example.weather',
 ],
 'payload' => [
 'iss' => 'APPLE_TEAM_ID',
 'iat' => time(),
 'exp' => time() + 3600,
 'sub' => 'com.example.weather',
 ],
]);
$url = 'https://weatherkit.apple.com/api/v1/weather/en_US/40.1013/-75.3836?dataSets=currentWeather,forecastDaily,forecastHourly';
$headers = [
 'Authorization: Bearer ' . $token,
 'Accept: application/json',
];

HS256 example

$jwt = $modules->get('TokenForge')->createJwt([
 'algorithm' => 'HS256',
 'secret' => 'super-long-secret',
 'key_id' => 'shared-secret-key',
 'payload' => [
 'iss' => 'local-service',
 'iat' => time(),
 'exp' => time() + 1800,
 ],
]);

RS256 example

$jwt = $modules->get('TokenForge')->createJwt([
 'algorithm' => 'RS256',
 'key_id' => 'rsa-key-id',
 'private_key_path' => '/site/assets/private/rsa-private-key.pem',
 'payload' => [
 'iss' => 'enterprise-service',
 'iat' => time(),
 'exp' => time() + 3600,
 ],
]);

Caching tokens

Use createCachedJwt($cacheKey, $options) for API tokens that can be reused until expiry.

$jwt = $modules->get('TokenForge')->createCachedJwt('meteo_apple_weatherkit', [
 'ttl' => 3300,
 'algorithm' => 'ES256',
 'key_id' => $keyId,
 'private_key_path' => $privateKeyPath,
 'headers' => [
 'id' => $teamId . '.' . $serviceId,
 ],
 'payload' => [
 'iss' => $teamId,
 'iat' => time(),
 'exp' => time() + 3600,
 'sub' => $serviceId,
 ],
]);

The public cache key names a logical token. Internally, TokenForge also fingerprints the token options, so changing algorithm, key id, TTL, key material or non-temporal claims creates a fresh cached JWT. Temporal claims (iat, exp, nbf) are excluded from the fingerprint so cache-friendly calls that use time() still reuse valid cached tokens until TTL expiry.

If payload.exp exists, the ProcessWire cache TTL is capped to exp - time() - 60.

Security notes

• No private keys are stored in ProcessWire module settings.
• Admin profiles store reusable non-secret values per user in the ProcessWire cache path.
• Prefer private_key_path over inline private_key.
• Use strict filesystem permissions for key files.
• Store keys outside web-served public paths when possible.
• TokenForge does not log private keys, secrets or generated JWT values.
• Error messages do not include private key contents, secrets or full JWTs.

ProcessWire module integration example

Other modules can depend on TokenForge and call its public API:

$tokenForge = $this->wire('modules')->get('TokenForge');
if (!$tokenForge instanceof TokenForge) {
 throw new WireException('This integration requires TokenForge module.');
}
$jwt = $tokenForge->createCachedJwt('my_provider_token', [
 'ttl' => 3300,
 'algorithm' => 'ES256',
 'key_id' => $options['key_id'],
 'private_key_path' => $options['private_key_path'],
 'headers' => [
 'id' => $options['team_id'] . '.' . $options['service_id'],
 ],
 'payload' => [
 'iss' => $options['team_id'],
 'iat' => time(),
 'exp' => time() + 3600,
 'sub' => $options['service_id'],
 ],
]);

Meteo Apple WeatherKit integration

The intended first consumer is a future apple provider in the Meteo module.

Meteo should store these settings:

• apple_team_id
• apple_service_id
• apple_key_id
• apple_private_key_path

The provider should request:

• currentWeather
• forecastDaily
• forecastHourly

TokenForge usage inside MeteoProviderApple:

$tokenForge = $this->module->wire('modules')->get('TokenForge');
if (!$tokenForge instanceof TokenForge) {
 $this->module->setLastError('Apple WeatherKit requires TokenForge module.');
 return false;
}
$jwt = $tokenForge->createCachedJwt('meteo_apple_weatherkit', [
 'ttl' => 3300,
 'algorithm' => 'ES256',
 'key_id' => $opts['apple_key_id'],
 'private_key_path' => $opts['apple_private_key_path'],
 'headers' => [
 'id' => $opts['apple_team_id'] . '.' . $opts['apple_service_id'],
 ],
 'payload' => [
 'iss' => $opts['apple_team_id'],
 'iat' => time(),
 'exp' => time() + 3600,
 'sub' => $opts['apple_service_id'],
 ],
]);

Meteo should normalize Apple WeatherKit data into its existing provider format:

• location
• current
• hourly
• daily
• units
• updated_at
• provider (Apple Weather)
• provider_url (https://developer.apple.com/weatherkit/)
• attribution (Weather)
• optional raw debug payload

Process module (admin UI)

After installation you get an admin page at:

• URL: /admin/setup/token-forge/
• Class: ProcessTokenForge

You can use it to:

• generate signed JWTs and inspect decoded header/payload/signature parts;
• start from Apple WeatherKit, Android/Firebase, Samsung-style or generic API presets;
• load and export Apple WeatherKit preset values;
• import Apple preset profile JSON from the Apple Profiles tab;
• validate key sources before token generation;
• view diagnostics and download diagnostics JSON;
• clear cached JWT entries by cache key;
• view and clear a session activity log.

Diagnostics payload format

The admin export Export diagnostics as file contains:

• generated_at (UTC ISO timestamp)
• checks with label, status (ok, warning, error) and details
• context with requested_algorithm and private_key_path

Troubleshooting notes

• If OpenSSL extension check fails, enable OpenSSL for the web PHP process.
• If Private key path is not readable, verify file existence and filesystem permissions for the same user that runs PHP.
• /site/... private key paths are resolved relative to the ProcessWire root.
• If auto key validation reports an issue, correct the key source and re-run the preset/import flow.

Changelog

See CHANGELOG.md for version history and update notes.

License

MIT

See LICENSE for full terms.
