Matrix Type

ProcessWire Matrix Type Module

A ProcessWire module for managing and displaying typed repeater matrix items with structured data extraction and flexible rendering.

Version: 1.1.0 Repository: github.com/mxmsmnv/InputfieldMatrixType

InputfieldMatrixType

Author: Maxim Semenov
Website: smnv.org
Email: maxim@smnv.org

If this project helps your work, consider supporting future development: GitHub Sponsors or smnv.org/sponsor.
License: MIT

The Problem

When working with ProcessWire's Repeater Matrix fields, identifying the type of each matrix item on the frontend is not straightforward:

• No built-in field exists to store human-readable type identifiers
• Extracting structured data from different matrix types requires repetitive code
• Creating JSON APIs or dynamic frontends becomes unnecessarily complicated

This module solves these problems by providing a dedicated fieldtype for storing type identifiers and a data processor for consistent extraction.

Overview

• FieldtypeMatrixType — Custom fieldtype for storing matrix item type identifiers
• InputfieldMatrixType — Admin interface for configuring matrix types
• MatrixDataProcessor — PHP class for extracting and structuring matrix data

Features

• Define unique type identifiers for each matrix item
• Set human-readable display names
• Automatic data extraction from repeater matrix fields
• Structured output format (JSON-ready)
• Built-in price and SKU field support
• Support for multiple field types (text, images, options, pages, etc.)
• Skip empty values automatically
• Preserve numeric zero values for number fields
• Filter system fields automatically
• Reliable type detection via native repeater_matrix_type + getMatrixTypes()

Installation

1. Copy the module folder to /site/modules/InputfieldMatrixType/
2. Go to Admin → Modules → Refresh
3. Install FieldtypeMatrixType — InputfieldMatrixType installs automatically as a dependency

Module Structure

/site/modules/InputfieldMatrixType/
├── FieldtypeMatrixType.module.php
├── InputfieldMatrixType.module.php
├── MatrixDataProcessor.php
└── README.md

Setup

Step 1 — Create identifier fields

For each matrix type, create a separate field of type Matrix Type (FieldtypeMatrixType).

Step 2 — Configure each identifier field

Go to Admin → Fields → [field name] → Details tab and fill in:

• Matrix Type Identifier — unique slug used in code (e.g. box)
• Display Name — human-readable label (e.g. Box)

⚠ The Matrix Type Identifier is what $item['type'] returns in your template. It must match exactly what you use in your switch/if statements.

Step 3 — Add to matrix templates

In each matrix type template, add its corresponding identifier field. The field renders as a hidden input in the admin — no data entry needed from editors.

Usage

⚠ Namespace requirement

Template files must declare the namespace, otherwise new MatrixDataProcessor() will fail:

<?php namespace ProcessWire;

Basic example

<?php namespace ProcessWire;
$processorPath = wire('config')->paths->siteModules . 'InputfieldMatrixType/MatrixDataProcessor.php';
if (file_exists($processorPath)) require_once $processorPath;
$processor = new MatrixDataProcessor($page);
$items = $processor->getItems('your_matrix_field_name');

Use wire('config') instead of $config — it works reliably in all template contexts.

Data structure returned

[
 [
 'id' => 1234,
 'type' => 'sedan', // Matrix Type Identifier
 'displayName' => 'Sedan', // Display Name
 'sku' => 'VIN-001', // SKU field value if present
 'price' => 24900.00, // Price field value if present
 'fields' => [ // All non-system fields with values
 [
 'name' => 'make',
 'label' => 'Make',
 'type' => 'FieldtypeText',
 'value' => 'Toyota'
 ],
 [
 'name' => 'year',
 'label' => 'Year',
 'type' => 'FieldtypeInteger',
 'value' => 2022
 ],
 [
 'name' => 'transmission',
 'label' => 'Transmission',
 'type' => 'FieldtypeOptions',
 'value' => ['Automatic']
 ],
 [
 'name' => 'all_wheel_drive',
 'label' => 'All Wheel Drive',
 'type' => 'FieldtypeCheckbox',
 'value' => true
 ],
 ]
 ]
]

Field value types

Empty values are skipped automatically — a field only appears in $item['fields'] if it has a non-empty value. Numeric 0 is preserved for number fields; unchecked checkboxes are skipped.

Examples

Case 1 — Real estate: Apartment, House, Land

Each property type has a completely different set of fields. Matrix field name: details

Identifier fields:

Fields per type:

Template:

<?php namespace ProcessWire;
$processorPath = wire('config')->paths->siteModules . 'InputfieldMatrixType/MatrixDataProcessor.php';
if (file_exists($processorPath)) require_once $processorPath;
$processor = new MatrixDataProcessor($page);
$items = $processor->getItems('details');
foreach ($items as $item):
?>
<div data-type="<?= $item['type'] ?>">
 <h3><?= $item['displayName'] ?></h3>
 <?php foreach ($item['fields'] as $f): ?>
 <?php
 $val = $f['value'];
 if (is_array($val)) $val = implode(', ', $val);
 if (is_bool($val)) $val = $val ? 'Yes' : 'No';
 if ($val === null || $val === '') continue;
 ?>
 <div>
 <span><?= htmlspecialchars($f['label']) ?></span>
 <span><?= htmlspecialchars((string)$val) ?></span>
 </div>
 <?php endforeach ?>
</div>
<?php endforeach ?>

Case 2 — Alcohol shop: Wine, Cognac, Beer

Each drink type has its own set of characteristics. Matrix field name: drinks

Identifier fields:

Fields per type:

Template:

<?php namespace ProcessWire;
$processorPath = wire('config')->paths->siteModules . 'InputfieldMatrixType/MatrixDataProcessor.php';
if (file_exists($processorPath)) require_once $processorPath;
$processor = new MatrixDataProcessor($page);
$items = $processor->getItems('drinks');
foreach ($items as $item):
?>
<div data-type="<?= $item['type'] ?>">
 <h3><?= $item['displayName'] ?></h3>
 <?php if ($item['price'] !== null): ?>
 <div>$<?= number_format($item['price'], 2) ?></div>
 <?php endif ?>
 <?php foreach ($item['fields'] as $f): ?>
 <?php
 $val = $f['value'];
 if (is_array($val)) $val = implode(', ', $val);
 if (is_bool($val)) $val = $val ? 'Yes' : 'No';
 if ($val === null || $val === '') continue;
 ?>
 <div>
 <span><?= htmlspecialchars($f['label']) ?></span>
 <span><?= htmlspecialchars((string)$val) ?></span>
 </div>
 <?php endforeach ?>
 <button data-item-id="<?= $item['id'] ?>">Add to Cart</button>
</div>
<?php endforeach ?>

Skip Fields

The processor automatically skips:

• System fields: id, name, parent, template, created, modified, createdUser, modifiedUser
• repeater_matrix_type
• price, sku (returned separately at the item level)
• All FieldtypeMatrixType fields (used for type detection only)

You can customize skipped fields without editing the class:

$processor = new MatrixDataProcessor($page, [
 'addSkipFields' => ['internal_notes', 'supplier_cost']
]);
// Or replace the full skip list:
$processor = new MatrixDataProcessor($page, [
 'skipFields' => ['repeater_matrix_type', 'id', 'name']
]);

Custom Formatting

Override formatValue() to add support for custom fieldtypes:

protected function formatValue($value, $field) {
 $fieldType = $field->type->className();
 switch($fieldType) {
 case 'YourCustomFieldtype':
 return $this->formatCustom($value);
 default:
 return parent::formatValue($value, $field);
 }
}

API Reference

// Constructor
$processor = new MatrixDataProcessor(Page $page, array $options = []);
// Get all items from a matrix field
$items = $processor->getItems(string $matrixFieldName = 'matrix');

Troubleshooting

Class "MatrixDataProcessor" not found
Add <?php namespace ProcessWire; at the top of your template file.

No items returned

• Verify the matrix field name: $processor->getItems('your_field_name')
• Check that items are published and the field has content

type returns "unknown"

• Ensure each matrix type template has a FieldtypeMatrixType field added to it
• Open the field in Admin → Fields → Details and fill in the Matrix Type Identifier

Requirements

• ProcessWire 3.0+
• PHP 8.1+

License

MIT — free to use and modify

Author: Maxim Semenov — maxim@smnv.org
Module Version: 1.1.0
