# Enable internet access for VPC-connected Lambda functions By default, Lambda functions run in a Lambda-managed VPC that has internet access. To access resources in a VPC in your account, you can add a VPC configuration to a function. This restricts the function to resources within that VPC, unless the VPC has internet access. This page explains how to provide internet access to VPC-connected Lambda functions. ## I don't have a VPC yet ### Create the VPC The **Create VPC workflow** creates all VPC resources required for a Lambda function to access the public internet from a private subnet, including subnets, NAT gateway, internet gateway, and route table entries. **To create the VPC** 1. Open the Amazon VPC console at [https://console.aws.amazon.com/vpc/](https://console.aws.amazon.com/vpc/). 1. On the dashboard, choose **Create VPC**. 1. For **Resources to create**, choose **VPC and more**. 1. **Configure the VPC** 1. For **Name tag auto-generation**, enter a name for the VPC. 1. For **IPv4 CIDR block**, you can keep the default suggestion, or alternatively you can enter the CIDR block required by your application or network. 1. If your application communicates by using IPv6 addresses, choose **IPv6 CIDR block**, **Amazon-provided IPv6 CIDR block**. 1. **Configure the subnets** 1. For **Number of Availability Zones**, choose **2**. We recommend at least two AZs for high availability. 1. For **Number of public subnets**, choose **2**. 1. For **Number of private subnets**, choose **2**. 1. You can keep the default CIDR block for the public subnet, or alternatively you can expand **Customize subnet CIDR blocks** and enter a CIDR block. For more information, see [Subnet CIDR blocks](https://docs.aws.amazon.com/vpc/latest/userguide/subnet-sizing.html) . 1. For **NAT gateways**, choose **1 per AZ** to improve resiliency. 1. For **Egress only internet gateway**, choose **Yes** if you opted to include an IPv6 CIDR block. 1. For **VPC endpoints**, keep the default (**S3 Gateway**). There is no cost for this option. For more information, see [Types of VPC endpoints for Amazon S3](https://docs.aws.amazon.com/AmazonS3/latest/userguide/privatelink-interface-endpoints.html#types-of-vpc-endpoints-for-s3). 1. For **DNS options**, keep the default settings. 1. Choose **Create VPC**. ### Configure the Lambda function **To configure a VPC when you create a function** 1. Open the [Functions page](https://console.aws.amazon.com/lambda/home#/functions) of the Lambda console. 1. Choose **Create function**. 1. Under **Basic information**, for **Function name**, enter a name for your function. 1. Expand **Advanced settings**. 1. Select **Enable VPC**, and then choose a VPC. 1. (Optional) To allow [outbound IPv6 traffic](configuration-vpc.md#configuration-vpc-ipv6), select **Allow IPv6 traffic for dual-stack subnets**. 1. For **Subnets**, select all private subnets. The private subnets can access the internet through the NAT gateway. Connecting a function to a public subnet doesn't give it internet access. **Note** If you selected **Allow IPv6 traffic for dual-stack subnets**, all selected subnets must have an IPv4 CIDR block and an IPv6 CIDR block. 1. For **Security groups**, select a security group that allows outbound traffic. 1. Choose **Create function**. Lambda automatically creates an execution role with the [AWSLambdaVPCAccessExecutionRole](https://docs.aws.amazon.com/aws-managed-policy/latest/reference/AWSLambdaVPCAccessExecutionRole.html) AWS managed policy. The permissions in this policy are required only to create elastic network interfaces for the VPC configuration, not to invoke your function. To apply least-privilege permissions, you can remove the **AWSLambdaVPCAccessExecutionRole** policy from your execution role after you create the function and VPC configuration. For more information, see [Required IAM permissions](configuration-vpc.md#configuration-vpc-permissions). **To configure a VPC for an existing function** To add a VPC configuration to an existing function, the function's execution role must have [ permission to create and manage elastic network interfaces](configuration-vpc.md#configuration-vpc-permissions). The [AWSLambdaVPCAccessExecutionRole](https://docs.aws.amazon.com/aws-managed-policy/latest/reference/AWSLambdaVPCAccessExecutionRole.html) AWS managed policy includes the required permissions. To apply least-privilege permissions, you can remove the **AWSLambdaVPCAccessExecutionRole** policy from your execution role after you create the VPC configuration. 1. Open the [Functions page](https://console.aws.amazon.com/lambda/home#/functions) of the Lambda console. 1. Choose a function. 1. Choose the **Configuration** tab, and then choose **VPC**. 1. Under **VPC**, choose **Edit**. 1. Select the VPC. 1. (Optional) To allow [outbound IPv6 traffic](configuration-vpc.md#configuration-vpc-ipv6), select **Allow IPv6 traffic for dual-stack subnets**. 1. For **Subnets**, select all private subnets. The private subnets can access the internet through the NAT gateway. Connecting a function to a public subnet doesn't give it internet access. **Note** If you selected **Allow IPv6 traffic for dual-stack subnets**, all selected subnets must have an IPv4 CIDR block and an IPv6 CIDR block. 1. For **Security groups**, select a security group that allows outbound traffic. 1. Choose **Save**. ### Test the function Use the following sample code to confirm that your VPC-connected function can reach the public internet. If successful, the code returns a `200` status code. If unsuccessful, the function times out. ------ #### [ Node.js ] 1. In the **Code source** pane on the Lambda console, paste the following code into the **index.mjs** file. The function makes an HTTP GET request to a public endpoint and returns the HTTP response code to test if the function has access to the public internet. ![Lambda console code editor.](http://docs.aws.amazon.com/lambda/latest/dg/images/code-source-nodejs.png) **Example — HTTP request with async/await** ``` const url = "https://aws.amazon.com/"; export const handler = async(event) => { try { const res = await fetch(url); console.info("status", res.status); return res.status; } catch (e) { console.error(e); return 500; } }; ``` 1. In the **DEPLOY** section, choose **Deploy** to update your function's code: ![Deploy button in the Lambda console code editor](http://docs.aws.amazon.com/lambda/latest/dg/images/getting-started-tutorial/deploy-console.png) 1. Choose the **Test** tab. ![Lambda console Test tab.](http://docs.aws.amazon.com/lambda/latest/dg/images/test-tab.png) 1. Choose **Test**. 1. The function returns a `200` status code. This means that the function has outbound internet access. ![Lambda console Test tab.](http://docs.aws.amazon.com/lambda/latest/dg/images/test-successful-200.png) If the function can't reach the public internet, you get an error message like this: ``` { "errorMessage": "2024-04-11T17:22:20.857Z abe12jlc-640a-8157-0249-9be825c2y110 Task timed out after 3.01 seconds" } ``` ------ #### [ Python ] 1. In the **Code source** pane on the Lambda console, paste the following code into the **lambda\_function.py** file. The function makes an HTTP GET request to a public endpoint and returns the HTTP response code to test if the function has access to the public internet. ![Lambda console code editor.](http://docs.aws.amazon.com/lambda/latest/dg/images/code-source-python.png) ``` import urllib.request def lambda_handler(event, context): try: response = urllib.request.urlopen('https://aws.amazon.com') status_code = response.getcode() print('Response Code:', status_code) return status_code except Exception as e: print('Error:', e) raise e ``` 1. In the **DEPLOY** section, choose **Deploy** to update your function's code: ![Deploy button in the Lambda console code editor](http://docs.aws.amazon.com/lambda/latest/dg/images/getting-started-tutorial/deploy-console.png) 1. Choose the **Test** tab. ![Lambda console Test tab.](http://docs.aws.amazon.com/lambda/latest/dg/images/test-tab.png) 1. Choose **Test**. 1. The function returns a `200` status code. This means that the function has outbound internet access. ![Lambda console Test tab.](http://docs.aws.amazon.com/lambda/latest/dg/images/test-successful-200.png) If the function can't reach the public internet, you get an error message like this: ``` { "errorMessage": "2024-04-11T17:22:20.857Z abe12jlc-640a-8157-0249-9be825c2y110 Task timed out after 3.01 seconds" } ``` ------ ## I already have a VPC If you already have a VPC but you need to configure public internet access for a Lambda function, follow these steps. This procedure assumes that your VPC has at least two subnets. If you don't have two subnets, see [Create a subnet](https://docs.aws.amazon.com/vpc/latest/userguide/create-subnets.html) in the *Amazon VPC User Guide*. ### Verify the route table configuration 1. Open the Amazon VPC console at [https://console.aws.amazon.com/vpc/](https://console.aws.amazon.com/vpc/). 1. Choose the **VPC ID**. ![VPC console list of VPCs.](http://docs.aws.amazon.com/lambda/latest/dg/images/vpc-id.png) 1. Scroll down to the **Resource map** section. Note the route table mappings. Open each route table that is mapped to a subnet. ![VPC console resource map section](http://docs.aws.amazon.com/lambda/latest/dg/images/route-table-associations.png) 1. Scroll down to the **Routes** tab. Review the routes to determine if your VPC has both of the following route tables. Each of these requirements must be satisfied by a separate route table. + Internet-bound traffic (`0.0.0.0/0` for IPv4, `::/0` for IPv6) is routed to an internet gateway (`igw-xxxxxxxxxx`). This means that the subnet associated with the route table is a public subnet. **Note** If your subnet doesn't have an IPv6 CIDR block, you will only see the IPv4 route (`0.0.0.0/0`). **Example public subnet route table** ![Public subnet route table with route to internet gateway](http://docs.aws.amazon.com/lambda/latest/dg/images/routes-public.png) + Internet-bound traffic for IPv4 (`0.0.0.0/0`) is routed to a NAT gateway (`nat-xxxxxxxxxx`) that is associated with a public subnet. This means that the subnet is a private subnet that can access the internet through the NAT gateway. **Note** If your subnet has an IPv6 CIDR block, the route table must also route internet-bound IPv6 traffic (`::/0`) to an egress-only internet gateway (`eigw-xxxxxxxxxx`). If your subnet doesn't have an IPv6 CIDR block, you will only see the IPv4 route (`0.0.0.0/0`). **Example private subnet route table** ![Private subnet route table with route to NAT gateway](http://docs.aws.amazon.com/lambda/latest/dg/images/routes-private.png) 1. Repeat the previous step until you have reviewed each route table associated with a subnet in your VPC and confirmed that you have a route table with an internet gateway and a route table with a NAT gateway. If you don't have two route tables, one with a route to an internet gateway and one with a route to a NAT gateway, follow these steps to create the missing resources and route table entries. ### Create a route table Follow these steps to create a route table and associate it with a subnet. **To create a custom route table using the Amazon VPC console** 1. Open the Amazon VPC console at [https://console.aws.amazon.com/vpc/](https://console.aws.amazon.com/vpc/). 1. In the navigation pane, choose **Route tables**. 1. Choose **Create route table**. 1. (Optional) For **Name**, enter a name for your route table. 1. For **VPC**, choose your VPC. 1. (Optional) To add a tag, choose **Add new tag** and enter the tag key and tag value. 1. Choose **Create route table**. 1. On the **Subnet associations** tab, choose **Edit subnet associations**. ![Attach internet gateway to VPC](http://docs.aws.amazon.com/lambda/latest/dg/images/route-table-subnet.png) 1. Select the check box for the subnet to associate with the route table. 1. Choose **Save associations**. ### Create an internet gateway Follow these steps to create an internet gateway, attach it to your VPC, and add it to your public subnet's route table. **To create an internet gateway** 1. Open the Amazon VPC console at [https://console.aws.amazon.com/vpc/](https://console.aws.amazon.com/vpc/). 1. In the navigation pane, choose **Internet gateways**. 1. Choose **Create internet gateway**. 1. (Optional) Enter a name for your internet gateway. 1. (Optional) To add a tag, choose **Add new tag** and enter the tag key and value. 1. Choose **Create internet gateway**. 1. Choose **Attach to a VPC** from the banner at the top of the screen, select an available VPC, and then choose **Attach internet gateway**. ![Attach internet gateway to VPC](http://docs.aws.amazon.com/lambda/latest/dg/images/igw-attach-vpc.png) 1. Choose the **VPC ID**. ![Internet gateway details page](http://docs.aws.amazon.com/lambda/latest/dg/images/igw-subnet-1.png) 1. Choose the **VPC ID** again to open the VPC details page. ![Filtered VPC list in Amazon VPC Console](http://docs.aws.amazon.com/lambda/latest/dg/images/igw-your-vpcs.png) 1. Scroll down to the **Resource map** section and then choose a subnet. The subnet details are displayed in a new tab. ![VPC console Resource map with list of subnets.](http://docs.aws.amazon.com/lambda/latest/dg/images/vpc-subnets.png) 1. Choose the link under **Route table**. ![Link to route table on subnet details page](http://docs.aws.amazon.com/lambda/latest/dg/images/subnet-route-table.png) 1. Choose the **Route table ID** to open the route table details page. ![Filtered route table list](http://docs.aws.amazon.com/lambda/latest/dg/images/route-table-id.png) 1. Under **Routes**, choose **Edit routes**. ![Routes list with Edit routes button](http://docs.aws.amazon.com/lambda/latest/dg/images/edit-routes.png) 1. Choose **Add route**, and then enter `0.0.0.0/0` in the **Destination** box. ![Add destination for new route](http://docs.aws.amazon.com/lambda/latest/dg/images/create-route-1.png) 1. For **Target**, select **Internet gateway**, and then choose the internet gateway that you created earlier. If your subnet has an IPv6 CIDR block, you must also add a route for `::/0` to the same internet gateway. ![Add target for new route](http://docs.aws.amazon.com/lambda/latest/dg/images/create-route-2.png) 1. Choose **Save changes**. ### Create a NAT gateway Follow these steps to create a NAT gateway, associate it with a public subnet, and then add it to your private subnet's route table. **To create a NAT gateway and associate it with a public subnet** 1. In the navigation pane, choose **NAT gateways**. 1. Choose **Create NAT gateway**. 1. (Optional) Enter a name for your NAT gateway. 1. For **Subnet**, select a public subnet in your VPC. (A public subnet is a subnet that has a direct route to an internet gateway in its route table.) **Note** NAT gateways are associated with a public subnet, but the route table entry is in the private subnet. 1. For **Elastic IP allocation ID**, select an elastic IP address or choose **Allocate Elastic IP**. 1. Choose **Create NAT gateway**. **To add a route to the NAT gateway in the private subnet's route table** 1. In the navigation pane, choose **Subnets**. 1. Select a private subnet in your VPC. (A private subnet is a subnet that doesn't have a route to an internet gateway in its route table.) 1. Choose the link under **Route table**. ![Link to route table on subnet details page](http://docs.aws.amazon.com/lambda/latest/dg/images/subnet-route-table.png) 1. Choose the **Route table ID** to open the route table details page. ![Filtered route table list](http://docs.aws.amazon.com/lambda/latest/dg/images/route-table-id.png) 1. Scroll down and choose the **Routes** tab, then choose **Edit routes** ![Routes tab on route table details page](http://docs.aws.amazon.com/lambda/latest/dg/images/route-table-edit-routes.png) 1. Choose **Add route**, and then enter `0.0.0.0/0` in the **Destination** box. ![Add destination for new route](http://docs.aws.amazon.com/lambda/latest/dg/images/create-route-1.png) 1. For **Target**, select **NAT gateway**, and then choose the NAT gateway that you created earlier. ![Add target for new route](http://docs.aws.amazon.com/lambda/latest/dg/images/create-route-nat.png) 1. Choose **Save changes**. ### Create an egress-only internet gateway (IPv6 only) Follow these steps to create an egress-only internet gateway and add it to your private subnet's route table. **To create an egress-only internet gateway** 1. In the navigation pane, choose **Egress-only internet gateways**. 1. Choose **Create egress only internet gateway**. 1. (Optional) Enter a name. 1. Select the VPC in which to create the egress-only internet gateway. 1. Choose **Create egress only internet gateway**. 1. Choose the link under **Attached VPC ID**. ![Egress-only internet gateway details page](http://docs.aws.amazon.com/lambda/latest/dg/images/eigw-details.png) 1. Choose the link under **VPC ID** to open the VPC details page. 1. Scroll down to the **Resource map** section and then choose a private subnet. (A private subnet is a subnet that doesn't have a route to an internet gateway in its route table.) The subnet details are displayed in a new tab. ![VPC console Resource map with list of subnets.](http://docs.aws.amazon.com/lambda/latest/dg/images/vpc-subnet-private.png) 1. Choose the link under **Route table**. ![Link to route table on subnet details page](http://docs.aws.amazon.com/lambda/latest/dg/images/private-subnet-route-table.png) 1. Choose the **Route table ID** to open the route table details page. ![Filtered route table list](http://docs.aws.amazon.com/lambda/latest/dg/images/route-table-id.png) 1. Under **Routes**, choose **Edit routes**. ![Routes list with Edit routes button](http://docs.aws.amazon.com/lambda/latest/dg/images/edit-routes.png) 1. Choose **Add route**, and then enter `::/0` in the **Destination** box. ![Add destination for new route](http://docs.aws.amazon.com/lambda/latest/dg/images/create-route-1.png) 1. For **Target**, select **Egress Only Internet Gateway**, and then choose the gateway that you created earlier. ![Add target for new route](http://docs.aws.amazon.com/lambda/latest/dg/images/eigw-route.png) 1. Choose **Save changes**. ### Configure the Lambda function **To configure a VPC when you create a function** 1. Open the [Functions page](https://console.aws.amazon.com/lambda/home#/functions) of the Lambda console. 1. Choose **Create function**. 1. Under **Basic information**, for **Function name**, enter a name for your function. 1. Expand **Advanced settings**. 1. Select **Enable VPC**, and then choose a VPC. 1. (Optional) To allow [outbound IPv6 traffic](configuration-vpc.md#configuration-vpc-ipv6), select **Allow IPv6 traffic for dual-stack subnets**. 1. For **Subnets**, select all private subnets. The private subnets can access the internet through the NAT gateway. Connecting a function to a public subnet doesn't give it internet access. **Note** If you selected **Allow IPv6 traffic for dual-stack subnets**, all selected subnets must have an IPv4 CIDR block and an IPv6 CIDR block. 1. For **Security groups**, select a security group that allows outbound traffic. 1. Choose **Create function**. Lambda automatically creates an execution role with the [AWSLambdaVPCAccessExecutionRole](https://docs.aws.amazon.com/aws-managed-policy/latest/reference/AWSLambdaVPCAccessExecutionRole.html) AWS managed policy. The permissions in this policy are required only to create elastic network interfaces for the VPC configuration, not to invoke your function. To apply least-privilege permissions, you can remove the **AWSLambdaVPCAccessExecutionRole** policy from your execution role after you create the function and VPC configuration. For more information, see [Required IAM permissions](configuration-vpc.md#configuration-vpc-permissions). **To configure a VPC for an existing function** To add a VPC configuration to an existing function, the function's execution role must have [ permission to create and manage elastic network interfaces](configuration-vpc.md#configuration-vpc-permissions). The [AWSLambdaVPCAccessExecutionRole](https://docs.aws.amazon.com/aws-managed-policy/latest/reference/AWSLambdaVPCAccessExecutionRole.html) AWS managed policy includes the required permissions. To apply least-privilege permissions, you can remove the **AWSLambdaVPCAccessExecutionRole** policy from your execution role after you create the VPC configuration. 1. Open the [Functions page](https://console.aws.amazon.com/lambda/home#/functions) of the Lambda console. 1. Choose a function. 1. Choose the **Configuration** tab, and then choose **VPC**. 1. Under **VPC**, choose **Edit**. 1. Select the VPC. 1. (Optional) To allow [outbound IPv6 traffic](configuration-vpc.md#configuration-vpc-ipv6), select **Allow IPv6 traffic for dual-stack subnets**. 1. For **Subnets**, select all private subnets. The private subnets can access the internet through the NAT gateway. Connecting a function to a public subnet doesn't give it internet access. **Note** If you selected **Allow IPv6 traffic for dual-stack subnets**, all selected subnets must have an IPv4 CIDR block and an IPv6 CIDR block. 1. For **Security groups**, select a security group that allows outbound traffic. 1. Choose **Save**. ### Test the function Use the following sample code to confirm that your VPC-connected function can reach the public internet. If successful, the code returns a `200` status code. If unsuccessful, the function times out. ------ #### [ Node.js ] 1. In the **Code source** pane on the Lambda console, paste the following code into the **index.mjs** file. The function makes an HTTP GET request to a public endpoint and returns the HTTP response code to test if the function has access to the public internet. ![Lambda console code editor.](http://docs.aws.amazon.com/lambda/latest/dg/images/code-source-nodejs.png) **Example — HTTP request with async/await** ``` const url = "https://aws.amazon.com/"; export const handler = async(event) => { try { const res = await fetch(url); console.info("status", res.status); return res.status; } catch (e) { console.error(e); return 500; } }; ``` 1. In the **DEPLOY** section, choose **Deploy** to update your function's code: ![Deploy button in the Lambda console code editor](http://docs.aws.amazon.com/lambda/latest/dg/images/getting-started-tutorial/deploy-console.png) 1. Choose the **Test** tab. ![Lambda console Test tab.](http://docs.aws.amazon.com/lambda/latest/dg/images/test-tab.png) 1. Choose **Test**. 1. The function returns a `200` status code. This means that the function has outbound internet access. ![Lambda console Test tab.](http://docs.aws.amazon.com/lambda/latest/dg/images/test-successful-200.png) If the function can't reach the public internet, you get an error message like this: ``` { "errorMessage": "2024-04-11T17:22:20.857Z abe12jlc-640a-8157-0249-9be825c2y110 Task timed out after 3.01 seconds" } ``` ------ #### [ Python ] 1. In the **Code source** pane on the Lambda console, paste the following code into the **lambda\_function.py** file. The function makes an HTTP GET request to a public endpoint and returns the HTTP response code to test if the function has access to the public internet. ![Lambda console code editor.](http://docs.aws.amazon.com/lambda/latest/dg/images/code-source-python.png) ``` import urllib.request def lambda_handler(event, context): try: response = urllib.request.urlopen('https://aws.amazon.com') status_code = response.getcode() print('Response Code:', status_code) return status_code except Exception as e: print('Error:', e) raise e ``` 1. In the **DEPLOY** section, choose **Deploy** to update your function's code: ![Deploy button in the Lambda console code editor](http://docs.aws.amazon.com/lambda/latest/dg/images/getting-started-tutorial/deploy-console.png) 1. Choose the **Test** tab. ![Lambda console Test tab.](http://docs.aws.amazon.com/lambda/latest/dg/images/test-tab.png) 1. Choose **Test**. 1. The function returns a `200` status code. This means that the function has outbound internet access. ![Lambda console Test tab.](http://docs.aws.amazon.com/lambda/latest/dg/images/test-successful-200.png) If the function can't reach the public internet, you get an error message like this: ``` { "errorMessage": "2024-04-11T17:22:20.857Z abe12jlc-640a-8157-0249-9be825c2y110 Task timed out after 3.01 seconds" } ``` ------
